Numatic TTV - 4555/100T User Manual

21
ALWAYS ENSURE THAT THE MACHINE IS ON LEVEL
GROUND BEFORE DISENGAGING BRAKE ARM.
NEVER DISENGAGE THE BRAKE WHEN THE MACHINE
IS ON A SLOPE / GRADIENT
!
!
The TTV-4555/100T is equipped with a free-wheel function that will enable the operator to move the machine manually
if required.
The motor brake is located on the right side of the machine near the rear
wheel (Fig 52).
Pull the arm out (Fig 53).
Swing to the disengaged position (Fig 54).
The motor brake will be fully disengaged.
The machine will now be in full free-wheel mode.
Note:
None of the other functions on the machine will work whilst in the Free Wheel Mode!.
Remember to re-engage the drive when you reach your nal destination / before using the machine.
Fig.52
Fig.53
Fig.54
WARNING!
WHEN THE BRAKE IS DISENGAGED THE MACHINE IS IN FREE-WHEEL MODE
AND HAS NO BRAKE FACILITY.
Free Wheel Function
