30 REVV
™
instructions
31REVV
™
instructions
1
Shoulder, Hip, and Crotch Pad
1
- ALWAYS use the shoulder, hip, and crotch pads.
To use the shoulder and hip pads, fold each pad in half over the harness strap and attach
the snaps.
2 - To use the crotch pad, slide the harness buckle through the loop on the pad.
3 - Locate and insert the tab/strap between the harness buckle and crotch strap. Pull the
tab through to the back of the harness buckle to secure the crotch pad.
Cup Holder
4
- Insert cup holder into opening on side of child restraint.
5 - To remove, lift up on the cup holder to release locking tab.
6 - Pull out to remove.
DO NOT place glass or metal containers or hard or sharp objects in cup holder. In a crash
they could cause serious injury. NEVER use cup holder for hot beverages.
4 6
5
2 3
