Operating Instruction and Documentation
2.35 TSK
- 10 -
3.Technical Information
3.1 Technical ratings
Capacity: 3500 kg
Load distribution: max. 2:1 in or against the drive on
direction
Lifting time: approx. 25 sec. with load
Lowering time: approx. 30 sec. with load
Lifting height: max: 1920mm
Line voltage: 400 V three phase current
Power rating: 3 kW
Motor speed: 2800 min-1
Pump capacity: 4,3 cm
3
Hydraulic pressure: approx. 240 bar
Pressure relief valve: approx. 260 bar
Oil tank: approx. 16 Litre - viscosity 32 cst.
Sound level L
PA
≤ 70 dB
Connection by customer (Observe the current voltage
of your Country)
3.2 Safety device
1. Safety ratchet (only versions with external hydraulic unit)
safety device against unintentional lowering
2. Pressure relief valve
Protects the hydraulic system from exceedingly high pressures.
3. Hydraulically unlocking holding valve
safety device against unintentional lowering
4. Lockable main switch
safety device against unauthorized operation
5. CE-Stop
safety device against squeeze
6. Locking safety system at the lifting arms
safety device against unintentional horizontal moving of the arms
