Nussbaum BT 642 - Bt 640; Bt 640 Mb

1 689 979 924N 26.11.07 91
18.3 BT 640 / BT 640 MB
Permissible force due to weight of axle kN 180
Permissible axle weight t 18
Max. braking force for each wheel kN 40
Test speed km/h 2,5
Nominal output kW 22
Star/delta starting circuit
Supply connection
3-phase current
Voltage Volts 400(380)
- Tolerance: % +5/-10
Frequency Hz 50
Protection AT 63
Display instruments measuring range
Braking force display kN 2 x 8/40
Scale diameter mm 350
Scale length mm 825
Communication display (optional extra) 14-digit
Font size, approximately mm 60
Display of operator notes
Braking pressure p
m
and p
z
bar 0...20
Braking force difference %
Weights daN
Deceleration (braking) %
Braking forces daN
Dimensions and weights:
Display unit:
Height mm 585
Width mm 900
Depth mm 325
Supporting column:
Height mm 1120
Diameter mm 205
Total height of display unit, mounted approx. mm 1680
Control cabinet:
Height mm 1 060
Width mm 900
Depth mm 330
Length of connecting lines:
Standard - cable set m 20, 32 or 45
(according to design)
Special - cable set (optional extra) m32
Special - cable set (optional extra) m45
Please observe foundation plan!
18.4
BT 642
Permissible force due to weight of axle kN 180
Permissible axle weight t 18
Max. braking force for each wheel kN 40
Test speed (truck/passenger car) km/h 2,5/5
Nominal output kW 22
Star/delta starting circuit (LKW)
Supply connection 3-phase current
Voltage
Volts 400(380)
- Tolerance: % +5/-10
Frequency Hz 50
Protection AT 63
Display instruments measuring range
Braking force display kN 2 x 8/40
Scale diameter mm 350
Scale length mm 825
Communication display (optional extra) 14-digit
Font size, approximately mm 60
Display of operator notes
Braking pressure p
m
and p
z
bar 0...20
Braking force difference %
Weights daN
Deceleration (braking) %
Braking forces daN
Dimensions and weights:
Display unit:
Height mm 585
Width mm 900
Depth mm 325
Supporting column:
Height mm 1120
Diameter mm 205
Total height of display unit, mounted approx. mm 1680
Control cabinet:
Height mm 1 060
Width mm 900
Depth mm 330
Length of connecting lines:
Standard - cable set m 20, 32 or 45
(according to design)
Special - cable set (optional extra) m32
Special - cable set (optional extra) m45
Please observe foundation plan!
