Operating Instruction and Documentation
SPL 4000
- 10 -
3 Technical Information
3.1 Technical ratings
Capacity 4000 kg / 9000 lbs
Load distribution max. 2:1
in or against the drive on direction
Lifting time approx. 55 sec
Lowering time according to the position of the lever
Lifting height max.1820 mm long/1740mm short
Line voltage 3~/N+PE, 400V, 50 Hz
Control voltage 24 V
Power rating 1,5 kW
Motor speed 1500 rotation/min
Hydraulic pump 4,2 cm³/rotation
Hydraulic pressure approx.220 bar
Pressure control valve approx. 240 bar
Oil tank approx. 10 liter
Sound level ≤ 75 dB (A)
Connection by customer 3~/N+PE, 400V, 50 Hz
fuse T16A (time-lag fuse)
observe your state regulations
3.2 Safety device
1. Safety device at the carrying arms.
Safety device against unintentional movement.
2. Equalization ropes
Safety device against inequality of the load.
3. Lockable main switch
Safety device against unauthorised operation
4. Foot-protection at the arms
Safety device to avoid crushing
5. Top limit switch
Safety against collision with the vehicle
6. Optional: additional top limit rope
Safety against collision with the vehicle
7. Press button
If not pressing the button any more, the lift stops the movement.
8. Safety ratchets
Safety device against unintentional lowering
