Operating Instruction and Documentation
SPL 4000
- 15 -
Electrical Parts List
M1 Motor 992463
F1 Fuse 9951863
F2 Fuse 990705
S1 Button “Lifting” 990334
S2 Button „Lowering“ 990366
K1M Motor Contactor 990842
S3 Top Limit Switch 990322
Y1 Magnet Coil 109503
Y2 Magnet Coil 109503
T1 Transformer 991002
Q1 Main Switch 9951257
X0 Jack / Plug 990407 + 990408
X1/2 Jack / Plug 990407 + 990408
X Strip Terminal 995205 + 9950189
3.6 Instruction for assembly to the change of 3x400V on 3x230V
SPL 4000- hydraulic unit with option:
We point out that reconnection may be accomplished only by an electrical specialist!
1. The controller housing is from the aggregate to loose (1 screws). The front cover
is to be removed. Afterwards can be begun with the change of wiring.
2. The light blue wire is to be taken off from the transformer. The prepared black wire, of
safety device F3, is to be attached to the transformer.
3. The engine is from star on delta connection to re-wire (s.g. also the circuit
diagrams in addition). It is the star bridge: to isolate yellow-red-white.
At the engine plug is: X1=1 yellow with brown X1=2 red with blue X1=3 white also
black to crimp.
4. Subsequently, everything is to be built again together in reverse order.
Attention! Please see the next Page!
