Operating Instruction and Documentation
SPL 4000
- 27 -
9.4 Initiation
Before the initiation a security check must be performed. Therefore use form: First
security check.
If the lift is installed by a competent person, he will perform this security check. If the operator
installs the lift by himself, he has to instruct a competent person to perform the security check.
The competent confirms the faultless function of the lift in the installation record and form for the
security check and allows the lift to be used.
Please send the filled installation record to the manufacturer after installation.
9.5 Changing the installation place
If the place of installation shall be changed, the new place has to be prepared in according to
the regulations of the first installation. The changing should be performed in accordance with
the following points:
• Raise the lift on approx. 800 mm
• Switch off the main switch and lock it.
• Loose and remove the plug of the power supply.
• Loose and remove all the covers.
• Drain off the oil tank.
• Dismount the carrying arms.
• Dismount the ropes. Loose only the ropes at the bottom of the carriage.
• Loose the pulley at the base plate and remove the ropes.
• Dismount the electrical cable of the ratchet magnet of the slave column.
• Remove the plastic tube.
• Loose the hydraulic pipe between the cylinders.
• Dismount the crossbeam.
• Loosen the dowels.
• Install the lift in accordance with chapter 8 ” Installation and Initiation”
Use new dowels, the used dowels can not be used anymore.
A security check must be performed before reinitiating by a competent person. Use
form “Regular security check”.
Pic. 4: choice of the dowel length without floor pavement or tile surface
