NuTone Evolve PTE511RK - Page 8

PTE511RK
n
PTE1115RK
n
PTEL511RK
n
PTEL1115RK Installation Guide
Page 8
BOOST
SWITCH
(purchase separately)
POWER
BOX
120 VAC LINE IN
SWITCH BOX
BLACK
WHITE GROUND (green or bare)
RED
CONTROL
SWITCH
(purchase separately)
Do not use a
speed control.
POWER
PANEL
14/4
2-FUNCTION
BOOST & TASK LIGHT
(purchase separately)
POWER
BOX
120 VAC LINE IN
SWITCH BOX
BLACK
WHITE GROUND (green or bare)
RED
CONTROL SWITCH
(purchase separately)
Do not use a
speed control.
POWER
PANEL
BLUE
14/3
14/4
New Construction/Retrofit Installation
PTE511RK - PTE1115RK
PTEL511RK - PTEL1115RK
FAN
BLK
WHT
WHT
GRD
GRD
SWITCH BOX
UNIT
LINE
IN
WHT
REDRED
REDRED
14/4
BOOST
SWITCH
CONTROL
SWITCH
BLK
BLK
FAN
BLK
WHT
WHT
GRD
GRD
SWITCH BOX
UNIT
LINE
IN
LIGHT
WHT
WHT
BLUBLU
REDRED
REDRED
BLK
WHT
14/3
14/4
TASK LIGHT/
DIMMER
SWITCH
BOOST
SWITCH
CONTROL
SWITCH
BLK
BLK
BLKBLK
TapeTape
Tape6" Ducting
4" Ducting
6
Insert Duct Connector and Attach Ducting
1
2
NOTE: 6" duct connector provided with 110-130-150 Selectable
CFM models PTE1115RK and PTEL1115RK.
NOTE: 6" duct connector and 4" reducer provided with 50-80-110
Selectable CFM models PTE511RK and PTEL511RK.
