4307 & 4310 Blower | 31
4307 & 4310 Blower Complete | Parts List Continued
PARTS LIST
DESCRIPTION
PART NUMBER
QTY
ITEM
BLOWER, 4307 CW LOW SHAFT131-4307-LD-B-LOC11
MANIFOLD, CW CAST AL 4307148-4307-002
1
2
WASHER, 5/16 SEALING BUNA
150-099-008123
GASKET, BALLAST MANIFOLD, 4307150-616-43072
4
BALLAST MANIFOLD, LH 4307 MACH150-650-0061
5
BALLAST MANIFOLD, RH 4307 MACH150-650-00716
HOSE, 3", TAR & ASPHALT-4 IN LG426-300-TAR-42
7
CLAMP, T-BOLT 3.875"
426-3875-TBC48
E-COAT BALLAST TEE W/ RISER,
4307 CAST803-650-009
1
9
HEX
HEAD CAP SCREW - 5/16-18 UNC X 3
HHCS - 5_16-18 UNC X 36301
HEX HEAD CAP SCREW - 5/16-18 UNC X 3.25
HHCS - 5_16-18 UNC X 3.256302
SOCKET HEAD PLUG - 1/4 NPTPLUG - 1_4 NPT SH2303
1
1
2
2
3
3
4
4
A A
B B
C C
D D
NVE
National
Vacuum
Equipment, Inc.
2707 Aero Park Drive, Traverse City, MI 49686
Phone: (231) 941-0215 Fax: (231) 941-2354
TOLERANCES UNLESS OTHER WISE SPECIFIED
One place (.X) ±.1
Two places (.XX) ±.01
Three places (.XXX) ±.005
Angles ±1°
All machined surfaces 125 RMS max.
Remove all burrs and sharp edges.
CAD drawing - NO manual changes.
All dimensions in inches unless specified.
This document may contain confidential trade
secret information which is the exclusive
property of National Vacuum Equipment. Any
information on this drawing is not to be
disclosed to anyone not having a "Need to
Know." The information contained herein is to
be used only in accordance with the best
interests of National Vacuum Equipment.
PART NAME:
MATERIAL:
DRAWN BY:
SCALE:
CHECKED BY:
DATE:
MEM
PART NO.SHEET
2
131-4307-LDM1
of
1 : 4
SEE BOM
APPROX. WT.
CAD FILE LOCATION: I:\Engineering\CAD - Production\131-4307-LDM.idw
SHEET SIZE C
371 LBS
BLOWER 4307 CW W/INTAKE MANIFOLD
REVISION HISTORY
REV DATE APPROVED DESCRIPTION ZONE
A
12/11/12
ISSUED FOR PRODUCTION
B
1/25/2013
ECN 1790
DRAWING UPDATED, 5/16 KNOBS
REMOVED FROM 148-4307-002
C
4/3/2014
ECN 1967 UPDATED TO MATCH BOM
-
D
7/8/2015
ECN 2150
ADDED REMOTE GREASE LINES, OIL
FILL, OIL VENT, AND FILTER COVER
HANDLE TO 148-4307-002
NOTES:
1. SEE 131-4307-LD AND 148-4307-002 FOR ASSEMBLY OF THE RESPECTIVE COMPONENTS AND
B
ILLS OF MATERIAL.
2. PERFORMANCE TESTING TO BE DONE ON THIS COMPLETED ASSEMBLY PER REQUIREMENTS
LISTED IN THE 131-4307-LD BLOWER DRAWING.
3.) REPLACE (120-047 - DRAIN PLUG 3/4'' NPT) & (150-047-003 - PLUG SAE ORB -12) WITH
(120-049-004 - BUSHING BRASS 3/4" X 1/4") & (320-408-030 - #12 MORB X 3/8" FNPT STRAIGHT)
FOR REMOTE OIL FILL AND VENT.
302
3
303
5
4
8
7
8
9
8
7
8
6
4
303
1
2
301
3
SEE NOTE #3
ITEM QTY PART NUMBER DESCRIPTION
1 1 131-4307-LD BLOWER, 4307 CW LOW SHAFT
2 1 148-4307-002 MANIFOLD, CW CAST AL 4307
3 12 150-099-008 WASHER, 5/16 SEALING BUNA
4 2 150-616-4307 GASKET, BALLAST MANIFOLD, 4307
5 1 150-650-006 BALLAST MANIFOLD, LH 4307 MACH
6 1 150-650-007 BALLAST MANIFOLD, RH 4307 MACH
7 2 426-300-TAR-4 HOSE, 3", TAR & ASPHALT-4 IN LG
8 4 426-3875-TBC CLAMP, T-BOLT 3.875"
9 1 803-650-009 E-COAT BALLAST TEE W/ RISER, 4307 CAST
301 6 HHCS - 5/16-18 UNC X 3 HEX HEAD CAP SCREW - 5/16-18 UNC X 3
302 6 HHCS - 5/16-18 UNC X 3.25 HEX HEAD CAP SCREW - 5/16-18 UNC X 3.25
303 2 PLUG - 1/4 NPT SH SOCKET HEAD PLUG - 1/4 NPT
4307 Blower 4-Way Intake Manifold | Parts Diagram
4307 Blower 4-Way Intake Manifold | Parts List
