32 | 4307 & 4310 Blower
4307 Blower 4-Way Manifold | Parts Diagram
4307 Blower 4-Way Manifold | Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 4 120-039-506 GASKET, 4" INT/EXH FLANGE
2 2 120-040 4-WAY VALVE SEAL 3" & 4" VITON
3 1 120-045 4-WAY FV SPRING (COMPRESSED)
4 1 120-059 PLUG, BRASS 1/4" NPT, HEX HD.
5 1 120-062-367 PLUG, 4-WAY W/ FILTER
6 1 120-064-003 O-RING, 2-240 VITON
7 2 120-064-012 O-RING, 2-350 VITON
8 1 120-065 TOWER, 4-WAY W/ FILTER
9 1 120-067-506 4-WAY HOUSING, 4" W/ FILTER
10 1 120-068 O-RING, 2-252 VITON
11 1 120-220 THERMOMETER, 50- 400 DEG, 2" FACE, 2.5" STEM, 1/4" -
18NPT
12 2 120-310 FILTER COVER
