4307 & 4310 Blower | 33
4307 Blower 4-Way Manifold | Parts List
4307 Blower 4-Way Manifold | Parts List Continued
ITEM QTY PART NUMBER DESCRIPTION
13 2 120-311 GASKET, FILTER HOUSING, 4-WAY
14 4 120-312 KNOB, 3/8-16 UNC
15 4 120-313 STUD, 3/8-16UNC-2A x 4-3/8" SS
16 1 120-314 FILTER ELEMENT, INLET 367/506
17 2 120-315 GASKET, FILTER COVER
18 1 150-041-007 CHECK VALVE FLAPPER, 4 IN SS
19 1 150-041-008 CHECK VALVE HOUSING 4307
20 2 150-063-001 ELBOW, ADJ 4" W/ 1/4 NPT
21 2 150-063-005 FLANGE, 4" ADJ-ELBOW
22 2 150-063-008 ELBOW MANIFOLD 4307 MACH
23 1 150-063-009 CHECK VALVE FLANGE MANIFOLD 4307 MACH
24 2 150-099-007 WASHER, #10 FLAT HD
25 1 150-099-010 WASHER, THRUST BRONZE, 5.25" OD .06"
26 1 150-309-4307 FILTER HOUSING, 4"
27 1 150-616-002 GASKET, 4" SQ INTAKE CHECK
28 1 412-060-005 HANDLE, 4307, OFFSET 4-WAY ADJ
29 1 412-060-005 HANDLE, 4307, OFFSET 4-WAY ADJ
301 2 FSCS - 10-24 UNC X 0.50 FLAT SOCKET CAP SCREW - 10-24 UNC X 0.50
302 1 FW - 3/8 X 1.75 WASHER, FENDER 3/8" x 1 3/4" X 3/16" THICK, PLATED
303 8 FW - 5/16 SAE FLAT WASHER, 5/16 SAE
304 1 HHCS - 3/8-16 UNC X 1.25 HEX HEAD CAP SCREW - 3/8-16 UNC X 1.25
305 8 HHCS - 3/8-16 UNC X 1.50 HEX HEAD CAP SCREW - 3/8-16 UNC X 1.50
306 8 HHCS - 5/16-18 UNC - 1.50 HEX HEAD CAP SCREW - 5/16-18 UNC - 1.50
307 8 HHCS - 5/16-18 UNC X 1.25 HEX HEAD CAP SCREW - 5/16-18 UNC X 1.25
308 4 HHCS - 5/16-18 UNC X 1.75 HEX HEAD CAP SCREW - 5/16-18 UNC X 1.75
309 4 HHCS - 5/16-18 UNC X 3.75 HEX HEAD CAP SCREW - 5/16-18 UNC X 3.75
310 4 HHCS - 5/16-18 UNC x 2.25 HEX HEAD CAP SCREW - 5/16-18 UNC x 2.25 FULL THREAD
311 9 LW - 3/8 LOCK WASHER, 3/8"
312 20 LW - 5/16 LOCK WASHER, 5/16"
313 4 NYLOCK NUT - 5/16 UNC NYLOCK NUT - 5/16 UNC
314 8 PLUG - 1/4 NPT SH SOCKET HEAD PLUG - 1/4 NPT
315 4 SHCS - 5/16-18 UNC X 1.50 SHCS - 5/16-18 UNC X 1.50
316 4
SHCS - 5/16-18 UNC X
0.875
SHCS - 5/16-18 UNC X 0.875
