4.3.7 “COMMUNICATIONS SETUP...” SUB-MENU
The settings found in this sub-menu must be configured whenever an optional
communications board is installed in the Control Module.
Table 4.10 Communications Setup
PROTOCOL = {HTCBUS or MODBUS ASCII
or MODBUS RTU}
HTCBUS ADDR = {1 to 16777215} (only if PROTOCOL=HTCBUS)
M
ODBUS ADDR = {1 to 247} (only if PROTOCOLHTCBUS)
M
ODBUS SUB ADDR = {0 to 31} (only if PROTOCOLHTCBUS)
BAUD RATE = {AUTO or 9600 or 4800
or 2400 or 1200 or
600 or 300}
PARITY = {NONE or ODD or EVEN} (only if PROTOCOLHTCBUS)
HARDWARE = {NONE OR MODEM OR
RS-232 or RS-485}
DRIVER = {AUTO or RS-485 or
RS-232 or MODEM}
P
ROFILE = {AUTO or 3-WIRE RS-232
or RS-485 or 1200 BAUD
MODEM or 300 BAUD
MODEM}
Tx DELAY = {0.00 to 2.50} S
---- END ----
CONTROL SETPOINT = 20C
LO TS 1 = –10C
LO LOAD = 1.0 A
HI GFI = 50 mA
GFI TRIP = 75 mA
TS ALARMS CONFIG…
OTHER ALARMS CONFIG…
POINT SETUP…
MISC SETUP…
COMMUNICATIONS SETUP…
