nvent RAYCHEM E-100-LR-A - Step F; Step G

nVent.com | 7
Be sure wires
are not caught
in threads.
F
• Push excess wire inside light. • Hand tighten light onto end seal stand.
• Insert cable tie through slots on stand and light then tighten.
Trim
Weather seal
G
• Leave these instructions with the end user for future
reference.
