Nvidia Mellanox ConnectX-4 Lx User Manual

47
[server1]# ./mlxup
Querying Mellanox devices firmware
...
Device
Type: ConnectX-4 Lx
Part
Number: MCX4131A-GCAT
Description:
ConnectX®-4 Lx EN network interface card, 50GbE single-port QSFP28, PCIe3.0 x8, tall bracket
PSID:
MT_2190110032
PCI Device Name: 0000:06:00.0
Base
GUID: e41d2d0300fd8b8a
Versions:
Current Available
FW 16.23.1020 16.24.1000
Status:
Update required
Device
Type: ConnectX-4 Lx
Part
Number: MCX4131A-GCAT
Description:
ConnectX®-4 Lx EN network interface card, 50GbE single-port QSFP28, PCIe3.0 x8, tall bracket
PSID:
MT_2170110021
PCI Device Name: 0000:07:00.0
Base MAC:
Versions:
0000e41d2da206d4
Current
Available
FW 16.24.1000 16.24.1000
Status:
Up to date
Perform FW update? [y/N]: y
Device #1:
Up to date
Device #2: Updating
FW ... Done
Restart needed for updates to take effect.
Log File: /var/log/mlxup/mlxup-yyyymmdd.log
Updating Adapter Firmware
Each adapter card is shipped with the latest version of qualified firmware at the time of manufacturing.
However, Mellanox issues firmware updates occasionally that provide new features and bug fixes. To
check that your card is programmed with the latest available firmware version, download the mlxup
firmware update and query utility. The utility can query for available Mellanox adapters and indicate
which adapters require a firmware update. If the user confirms, mlxup upgrades the firmware using
embedded images. The latest mlxup executable and documentation are available from http://
www.mellanox.com > Products > Software > Firmware Tools.
Firmware Update Example
