Quadro K4000/K5000/K6000 SDI DU-05337-002_v01
|
44
APPENDIX A ONBOARD DIP SWITCH
The Quadro SDI graphics card has an onboard dip switch, located on the SDI output
card, that determines the default SDI operating mode. Subsequent software changes
override these settings.
Figure A.1 Onboard DIP Switch Positions
(7) Auto Switch (See Table A.3)
(5-6) Sync Source (See Table A.2)
(1-4) Output Video Format (See Table A.1)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nvidia Quadro K4000 and is the answer not in the manual?

Nvidia Quadro K4000 Specifications

General IconGeneral
CUDA Cores768
GPU Memory3 GB GDDR5
Memory Interface192-bit
Memory Bandwidth134 GB/s
Maximum Power Consumption80 W
Form FactorSingle-slot
Display Connectors2x DisplayPort, 1x DVI
