NVIDIA Spectrum-4 SN5000 2U Switch Systems Hardware User Manual 22
Securing the System in the Switch Rails (A)
Chassis' Pins in the Rails' Slots Locking them in a Fixed Position
3. Mount both of the rack rails (B) into the rack by angularly inserting the brakes
located at the rails edges into the designated slots in the rack unit, as shown in the
following figure:
