1. Make sure the mating connector of the new unit is free of any dirt and/or obstacles.
2. Make sure that the board connector is located on the right (looking from the
system's rear side forward), and insert the unit by sliding it into the opening, until a
slight resistance is felt.
3. Continue pressing the power supply unit until it seats completely. The latch will
snap into place, confirming the proper installation.
4. Insert the power cord into the supply connector.
5. Insert the other end of the power cord into the AC outlet/PDU of the correct voltage.
Fans
The system has 3+1 fan module redundancy. Full operation is possible with 3 fans only.
Important
Do not attempt to insert a power supply unit with a power cord
connected to it.
Important
The green power supply unit indicator should light. If it does
not, repeat the whole procedure to extract the power supply
unit and re-insert it.
Important
Make sure that the fans configuration matches the model number.
Operation with incorrect fan configuration can cause over-
