LPC2468 IRD Kit 1.2 Quick Start Guide, rev. 1.0 Page 2 of 8
2.0 Assembling the Hardware
2.1. Packing List
The IRD kit includes the following:
1. LPC1768 “Processor Core Board”
2. NXP Industrial Reference Design (IRD) “Baseboard”, version 1.3
3. LCD Display Lumex model# LCM-S02004DSR
4. Display ribbon cable (assembled on the LCD/VFD Display)
5. NXP I
2
C keypad, version 1
6. External temperature sensor (2N3906-type red/white cabled temperature sensor)
7. Condor 5VDC 2.5A power supply
8. Ethernet Cable
9. USB A/B cable
10. RS232 cable
11. Keil ULINK-ME JTAG Debugger and cables
12. QuickStart Guide (this document )
Contact your supplier if components are missing.
The kit may also include other components as NXP bundles this kit with other reference
platforms (e.g. CAN Board, DALI Solid State Lighting Board, etc). If other components are
included, see the guide associated with that platform. The guide can be found on the included
CD.
2.2. Kit Assembly
The IRD demonstration code programmed into the LPC1768 MCU enables GPIO LED
“Blinky” and provides a baseline for customers to start their LCP17xx development.
1. Connect the following boards as shown in Figure 1 (next page):
- LCD display: Connected to J_VFD
- I
2
C Keypad: Connected to J_KEYPAD
- External temperature sensor: Connected to J_TEMP
(Red wire to D+, White to D-)
Please read carefully the following assembly
instructions. Failure to follow these instructions
may cause the platform not to function properly.
The following instructions apply to the IRD
platform only.
