3.0 Troubleshooting
A few common problems that can occur when operating the IRD are:
1. Hardware related issues:
The keypad and the LCD need to be correctly connected to the “Baseboard”. Refer to section
2.2 of this manual for more information
All jumpers must be configured as per section 2.2 of this manual
The keypad will not respond if the user unplugs and plugs it back in while the IRD is still
powered. When this happens, power down the board and power it up again
4.0 Information and Documents on CD’s
4.1. Documentation
The kit includes a copy of this QuickStartQuickStart Guide.
Schematics, Bill of Material, Gerber files for the Baseboard, IRD User Interface html web
pages, and training modules for the major functions of the IRD platform can be found on NXP
website:
http://www.standardics.nxp.com/support/boards/ird/
4.2. Software – Keil
The IRD LPC1768 kit software was developed using KEIL uVision3 version 3.5. Keil is
providing a 60 day, 256kB trial version for customers using the IRD kit.
To install the Keil IDE go to:
https://www.keil.com/demo/eval/arm.htm
1. Follow the instructions in the Auto-Installer window.
2. During the installation process, it is required to register the product with Keil to receive
the license key for the IDE. You will be asked to enter the PSN number provided in this
kit (label with 15 digit serial number) to register the trial version of uVision.
3. You then will receive the license key for the tool via email. This may take up to 24 hours
to process.
4.3. Software – ULINK-ME Debugger
The ULINK-ME Debugger that is included in the IRD kit allows code debugging and
programming of the LPC1768 Cortex-M3 microcontroller.
1. Connect the ULINK-ME to a PC USB port
2. Connect the JTAG connector to the JTAG port in the IRD Base Board
5.0 Software and Document Updates
Software and documentation updates are available from:
http://www.standardics.nxp.com/support/boards/ird/
