Installation: Rough-In Checklist
19
Installation: Rough-In Checklist
Infrastructure must sometimes be installed prior to the installation of the unit. Items
to consider for “Rough-In” installation include:
Potable water pipes to and from storage tanks, including pipe insulation and
heat tracing as necessary.
Primary power wiring.
Controls/freeze protection 120v power wiring, from a backed-up power source.
Condensate drain lines, including pipe insulation and heat tracing as necessary.
Ducting to or from remote locations, including insulation as necessary.
Control wiring for alarms, BMS interface, and external accessories. Nyle
recommends running a minimum of two 18/8 control wires and a CAT-5e/6
wire to ensure that all likely accessories and control functions could be utilized.
Site prep for mounting the heat pump.
Please refer to the appropriate sections of the manual for the specific details
associated with each item.
