Installation: Conﬁguration

Setting conﬁguration options for the heat pump will require active

120v power, or main power if the uniﬁed power package is installed.

While activating the 120v power for programming is safe, turning

compressor operation “on” at this stage is not. Complete the Pre-

Startup Checklist before pressing the “on” button in the control

interface! Operating the heat pump compressor before all checks

have been performed can result in severe equipment damage or major

component failure.

This manual addresses conﬁguration of individual heat pump water heaters. For

projects with centralized controllers connected to multiple heat pumps, or BMS

control systems, be sure to refer to additional instructions for the conﬁguration of

those accessories.

Heat Pump Controller Screens:

Your heat pump comes with a full color touchscreen mounted on the front of the

cabinet, under a weatherproof enclosure. Whenever 120v power is available, the

controller will be active. There are 4 primary screens that may be used during

installation and typical operation.

Monitor Screen: This is the default display screen, and features a variety of

indicators related to the current operation of the unit, but does not provide for

any conﬁguration options.

Conﬁgure Screen: This screen requires installation of a service jumper

between terminals 24v and i7 to allow access. All standard conﬁgurable

parameters are available in this screen, including operating mode, target

setpoints, and others.

Diagnose Screen: This screen requires installation of a service jumper

between terminals 24v and i7 to allow access. Operating information speciﬁc

to troubleshooting and diagnostics are available here, as well as selected

diagnostic and/or commissioning tools.

Alarms Screen: This screen is always accessible, and shows all available

alarms, their current status, and provides access to the error history.

Following is guidance for the setup and conﬁguration of the heat pump water

heater for its standard modes of operation.
