Performance Specifications & Requirements
8
Performance Specifications and Requirements
Heating and
Cooling
Heating Capacity at 70 F ** 287,000 BTUs/hr
Heating Capacity at 10 F ** 98,000 BTUs/hr
Cooling Capacity at 70 F * 211,000 BTUs/hr
Recovery Rate *** 380 Gallons/hr
Outdoor Temperature Operating Range 10-120 Deg. F
Water Inlet Operating Range 35-115 Deg. F.
Water Outlet Operating Range 80-160 Deg. F.
Mechanical
Water Side Maximum Flow 16 GPM
Available External Pressure Drop for Piping 15 Ft. Hd.
Maximum Water Side Pressure 150 PSIG
Minimum Tank Cycle Volume **** 157 Gallons
Design Air Side Flow 16,000 CFM
Available External Static for Ducting 1.5 In. W.C.
Refrigerant R513a
Typical Refrigerant Pressure High Side 130-395 PSIG
Typical Refrigerant Pressure Low Side 5-87 PSIG
Max Sound Pressure (Front/Left/Right/Rear) ***** 78.5/70.2/70.7/79 dBA
Quiet Mode Sound Pressure ***** 70.4/64.1/65.8/71.7 dBA
Salt Spray resistance Cabinet/Evap 9000/1000 hours
Table 1: Performance Specifications
*Note: Cooling is incidental to heating operation and should typically be considered supplemental, not primary space cooling.
**Nominal heating performance is outdoor air at 50% RH, 140 Deg.F. outlet and 50 Deg.F. inlet water temps.
***Recovery Rate assumes 70 Deg. F. outdoor temp, 140 Deg.F. storage temp and 50 Deg.F. inlet water temp.
****Minimum Tank Cycle Volume is the min volume between tank sensor and and heat pump inlet pipe, in the storage tank.
*****Sound Pressure measured 3’ away 3’ from ground, at max and quiet mode fan speeds, with ductless cowl installed.
