Installation: Transportation, Placement, Mounting

Placement considerations for the heat pump:

1. Ensure the location meets all requirements for ambient temperature,

structural support, unit dimensions, operational and service clearances. See

performance and physical speciﬁcations to conﬁrm.

2. Mounting location must be level and stable.

3. Unit location should be easily accessible for visual inspection and for regular

service. Placement should allow for possible heat pump removal/replacement

in the future.

4. Unit location should be as close as possible to conditioned space to allow for

the minimum piping and heat tracing possible in exterior environments, and

as close as possible to condensate drainage points, hot water storage tanks,

cold water source, and any air intake/discharge locations.

5. Unit location should minimize the risk of water damage in the event of leaks

or drainage failure.

6. Unit should be mounted high enough to ensure condensate piping pitch to a

remote drain point, or to a condensate pump in conditioned space for further

handling.

7. Unit location should consider the impact of operating noise and potential

vibration on the surroundings and mitigate these impacts as appropriate.

8. Location should provide adequate protection to the unit from vehicles, plows,

falling objects, or other potential sources of damage.

9. If unit location is indoors, ensure adequate ventilation or internal heat gain is

present to allow for unit operation, and/or that optional ducting is installed.

Mounting the heat pump:

The e-Series heat pump must be mounted on a solid, level base, typically a

concrete pad. Unit should be bolted securely to the base using the supplied

attachment points. If the base is not level, then the heat pump itself must be leveled

to ensure proper condensate drainage and mounting stability.

Mounting the unit on elevated rails is also possible. Complete structural

requirements for rails are beyond the scope of this manual: however, required rail

positions and minimum rail widths are speciﬁed in the following diagram to properly

support the internal structure of the heat pump.
