O2 Concepts LIBERTY2 User Manual

9
Specifications
Dimensions
Device Dimensions
H: 10 in (25.4 cm)
W: 9 in (22.9 cm)
D: 3.5 in (8.9 cm)
Weights
Device Weight
6.36 lbs. (2.88 kg)
Battery
1.14 lbs. (0.52 kg)
AC Charger
1.60 lbs. (0.72 kg)
DC Charger
0.39 lbs. (0.17 kg)
Modes of Operation
Continuous Mode
301-0005V
Five Settings, 0.5 to 1.5 in 0.25 LPM increments.
301-0005VP
Seven settings, 0.5 to 2.0 in 0.25 LPM increments.
Maximum deviation in flow rate is ± 10%. Flow
maintained with outlet pressure ranging from 0 to 5.0
psig (0-34kPa)
Pulse Mode
301-0005V
Settings 1 to 9 (160ml to 1500mL/minute)
Bolus volumes are in 8mL increments,
from 8 to 75mL.
301-0005VP
Settings 1 to 10 (160ml to 1600ml/minute)
Bolus volumes are in 8mL increments, from 8 to 80mL
Maximum deviation of volume per breath is
± 15% across all environmental conditions.
Breath Sensitivity
The device will deliver a bolus based on a trigger
pressure range of -0.08 to -0.35 cmH2O.
Battery Specification
Rechargeable 14.4V Lithium-Ion Battery
External Power
Supply Power Input
AC power: 100 - 240 VAC, 50/60 Hz@ 2.5 amps
DC power: 11.5-15 VDC; Recommended: 10A
outlet at 12V
Operating Altitude
0-13,123ft or (0-4000m)
