Ocean Digital WR-210CB - Location of Controls

Location of Controls
1. Standby button
2. Right button
3. Left / Back button
4. Preset button
5. Local button
6. Home
7. Infrared remote sensor
8. Speaker
9. TFT display 2.4”
10. Rotary control knob for Volume/Dial/Select – Rotate
to adjust the volume/browsing menu, press the knob to
select for confirmation
11. Aux-in jack
12. Earphone jack
13. Line out jack
14. DC IN jack
1
2
3
4
5
6
7
8
9
10
DCIN5.9V
Aux-in
11 12
13
14
- 01 -
