9
Installation
Mounting the Head
The 1040 is installed onto standard tripods using the 100mm ball
base and tie down
Other bases are available See optional accessories).
WARNING!
that cannot support the combined mass of the head and its
full payload.
WARNING!
tripod.
Refer to the tripod instructions supplied with the tripod for
Leveling the Head
After securely mounting the head on to the tripod, center the bubble
level to set the level.
If necessary, in poor light conditions:
1. Press the button illumination bubble (the light will remain on for
20 seconds).
Ball Base
bubble.
Tighten the bowl clamp and re-check the level.
