13
Mounting the Camera
WARNING!
WARNING! For safe and reliable operation the head and all mounted equipment must be correctly balanced.
Payload Weight and C of G Height Adjustment
@ 4” (100mm) <52 lb. (23.5 kg)
@ 5” (127mm) <45 lb. (20.4 kg)
@ 8” (203mm) <33 lb. (14.9 kg)
Installation
Tip.
reduce the total payload that can be
balanced.
approximation can be the distance
from the bottom of the camera plate to
the centre of the lens.
Approximate estimate for
H
CAMERA WEIGHT
CAMERA CENTER OF GRAVITY
ABOVE PLATFORM
in
lbs
kg
14
12
10
8
6
4
2
0
4.5 9 14 18 23 27 32 36
10 20 30 40 50 60 70 80
356
305
254
203
152
102
51
mm
1040 COUNTERBALANCE CHART
BALANCED
AREA
H H
