20
Maintenance
Adjust Lock Levers
If the pan and / or tilt friction locks do not fully engage at the end of
1. Rotate the lock lever to the locked position.
2.
the screw
3.
away from the “locked” end of the travel, and reinstall it.
4. Tighten the screw. Reapply the lock label.
1 Lock Shaft
2 Tilt Lock Lever
3 Screw
4 Lock Label
1
2
3
4
