Optional Accessories
1
2
3
4
5
8
12
1 Assistants box 
2 Front box mount 08308
3 Eye piece leveller 
Platform Assemblies & Plates
4
Large Euro quick release (includes large Euro
Plate Part No. 08285)

5

Plate Part No. 08427)
V4045-1901
Tripods + Hi Hats
6 100mm Hi Hat 45A-0002
30L Tripod (Not Shown) 
7  
Bases
8 Mitchell Base assy. 100mm 08281
9 Mitchell Tiedown 
10 150mm Ball Base 08414
11 150mm Ball Tiedown 
12 Studio Pedestal / Tripod Adaptor 08349
