Installation
Balancing the Payload
The purpose of setting the balance and counterbalance of the
payload is to negate the weight of the payload when tilting the head.
any set position throughout the tilt range.
Ensure the head is level before balancing. The camera and payload
achieved by moving the camera forwards (Fore) or backwards (Aft)
on the cradle.
WARNING! When positioning the payload, it is important
to be aware of the potential danger that an unbalanced
payload will fall away suddenly.
the handle, until the balance is set correctly.
WARNING! The payload balancing procedure may require
the assistance of another person.
Caution! The camera, handles and all accessories must
the head.
1. Make sure the tilt lock is engaged and that the camera and all
accessories are installed in their operating positions.
2.
3.
Depending on the payload weight, it may be necessary to
increase or decrease this setting to enable the payload to
be correctly balanced fore and aft.
Tilt Lock
Counterbalance
Crank
Tilt Adjust
