oConnor 1040 - Pan and Tilt Fluid Drag

17
Operation
Operating the Pan and Tilt Locks
The pan and tilt friction locks are operated by the levers on the left side of the head.

The levers are designed so they can be released simultaneously with one hand.
Pan
Tilt
