oConnor 1040 - Installation; Mounting the Head; Leveling the Head

8
Components
Position Description
1 Handle clamp
2 Pan handle
3 
4

handle
5 Provision for attachments
6 Pan drag indicator wheel
7 Battery compartment
8 
9 Bubble level
10 Tilt lock lever
11 Bubble illumination button
1
Rear View
3
4
5
6
7
8
9
10
11
2
