1.GENERAL INFORMATION
1-6
TIGHTENING TORQUE
Locking devices ( e.g.: locking tabs, elastic stop nuts ,self-locking fasteners ,etc.) must be installed or replaced
with new ones, where specified. If the efficiency of a locking device is impaired, it must be renewed.
In order to avoid a poor assembling, tighten screws, bolts or nuts in accordance with the following
recommended torque value:
Grade
Torque (N·m)
M6
M8
M10
M12
M14
M16
4.6
4～5
10～12
20～25
36～45
55～70
90～110
5.6
5～7
12～15
25～32
45～55
70～90
110～140
6.8
7～9
17～23
33～45
58～78
93～124
145～193
8.8
9～12
22～30
45～59
78～104
124～165
193～257
10.9
13～16
30～36
65～78
110～130
180～201
280～330
12.9
16～21
38～51
75～100
131～175
209～278
326～434
Grade
Torque (lbf.ft)
M6
M8
M10
M12
M14
M16
4.6
3～3.7
7.4～8.6
14.8～18.5
26.6～33.2
40.6～51.7
66.4～81.2
5.6
3.7～5.2
8.9～11.1
18.5～23.6
33.2～40.6
51.7～66.4
81.2～103.3
6.8
5.2～6.6
12.5～17
24.4～33.2
42.8～57.6
68.6～91.5
107～142.4
8.8
6.6～8.6
16.2～22.1
33.2～43.5
57.6～76.8
91.5～121.8
142.4～189.7
10.9
9.6～11.8
22.1～26.6
48～57.6
81.2～95.9
132.8～148.3
206.6～243.5
12.9
11.8～15.5
28～37.6
55.4～73.8
96.7～129.2
154.2～205.2
240.6～320.3
CAUTION
Bolt length comparison table
Length(mm)
12
14
16
20
25
30
35
40
Length(in)
0.47
0.55
0.63
0.79
0.98
1.18
1.38
1.57
Length(mm)
45
50
55
60
65
70
75
80
Length(in)
1.77
1.97
2.17
2.36
2.56
2.76
2.95
3.15
Length(mm)
85
90
95
100
105
110
115
120
Length(in)
3.35
3.54
3.74
3.94
4.13
4.33
4.53
4.72
Length(mm)
125
130
135
140
145
150
155
160
Length(in)
4.92
5.12
5.31
5.51
5.71
5.91
6.1
6.3
Length(mm)
165
170
175
180
185
190
195
200
Length(in)
6.5
6.69
6.89
7.09
7.28
7.48
7.68
7.8
Be sure to use the proper tightening torque for the proper strength grade. Always torque screws, bolts and / or
nuts in a criss-cross sequence.
