1.GENERAL INFORMATION
1-7
As for important tightening torques , please refer to following standards.
Installation location
Specifications (mm)
Torque N.m(lbf.ft)
Fastening bolt of engine
M10
70(51.6)
Fastening nut of suspension arm
M10
70(51.6)
Bolt of rear shock absorber
M10
80(59)
Bolt of front shock absorber
M10
80(59)
Fastening nut of wheel rim
M10
80(59)
Nut of wheel hub
M18
250(184.5)
Bolt of rear brake/stop pump (calipers)
M10
80(59)
Rear Brake / Brake disc bolts
M8
26(19.2）
Bolt of front brake/stop pump (calipers)
M8
26(19.2)
Front Brake / Brake disc bolts
M6
15(11)
Lock nut of steering rod
M8
40(29.5)
Bolt of exhaust pipe
M6
15(11)
Spark plug
M10
20(14.8)
Adjusting nut of valve clearance
M6
12(8.9)
Main pulley bolt
M12
100(73.8)
Driven pulley bolt
M10
60(44.3）
Magneto flywheel bolt
M16
150(110.7)
Magneto stator bolt
M6
12.5(9.2)
One way bolt
M8
30(22.1)
Engine oil drain plug
M10
20(14.8)
Gearbox oil drain plug
M12
20(14.8)
Decompression valve plug
M22
20(14.8)
Cylinder head bolt
M6
15(11）
Connecting rod bolt
M8
50(36.9)
Timing chain wheel bolt
M8
30(22.1)
