Electrical and Mechanical
Environmental
IEC 60954 Classication Protected
Degree of Protection IP67
Operating Temperature -20 to +70°C
Storage Temperature -30 to +80°C
Relative Humidity 93%RH @40° per IEC60945-8.2
Vibration 2-13.2Hz @ ±1mm, 13.2-100Hz @ 7m/s2 per IEC 60945-8.7
Electromagnetic Emission Conducted and Radiated Emission per IEC 60945-9
Electromagnetic Immunity Conducted, Radiated, Supply, and ESD per IEC 60945-10
Safety Precautions Dangerous Voltage, Electromagnetic Radio Frequency per IEC
60945-12
Operating Voltage 10 to 32 Volts
Power Consumption 250mA
Load Equivalence Number 5
Reverse Battery Protection Indenitely
Load Dump Protection Yes to SAE J1113
Size 95mm (W) x 95mm (H) x 23mm forward and 23mm rear (D)
Weight 160gm
