1.5 SPECIFICATIONS
Complete specification for the Ohaus adventurer balances are listed in Table 1-2. When a balance has been
serviced, it must meet the specifications listed in the table. Before servicing the balance, determine what
specifications are not met.
TABLE 1-2. ADVENTURER SPECIFICATIONS
Capacity (g) 65 120 220 150 220 320 420 420/100
520 1500 2200 3200 4200 4200/100
4200
Readability 0.1mg 0.001g
0.01/
0.001g
0.01g
0.1/
0.01g
0.1g
Weighing units/modes g, kg, mg, ct, lb, oz, gn, dwt, percent, Parts Counting
Repeatability (Std. Dev.) 0.1mg 0.001g
0.01/
0.001g
0.01g
0.1/
0.01g
0.1g
Linearity ±0.2mg ±0.3mg ±0.002g 0.003g
±0.01
/0.001g
0.01g
±0.02g ±0.03g
0.1/
0.01g
±0.1g
Tare Range Full capacity by subtraction
Stabilization Time (s) 4s 3s 2s
Sensitivity Drift 4ppm/°C 10ppm/°C
Operating Temp Range 50° to 86° F/10° to 30° C
Power Requirements 8.5 - 14.5V 50/60Hz 4VA or 8.5 - 20V 4W
Calibration 60g 100g 200g 150g 200g 300g
400g 400g 500g
1500g
2000g 3000g 4000g
Pan Size (in/cm) 3.5/9 dia. 3.9/10 dia. 7.1/18 dia.
Draft shield clearance
height above pan (in/cm)
9.3/23.6 6.8/17.25 ---
Dimensions (WxHxD) (cm) 36.6x11x34.3 21.7x21x34.3 21.7x11x34.3
Net Wt (lb/kg) 10.5/4.8 10/4.5 8.5/3.9
Shipping Wt (lb/kg) 17/7.8 16/7.3 14/6.4
Item No.
AR
64
AR
124
AR
224
AR
153
AR
223
AR
323
AR
423
AR
423D
AR
522
AR
1502
AR
2202
AR
3202
AR
4202
AR
4202D
AR
4201
Admissible ambient conditions
Use only in closed rooms
Temperature range: 50°F to 86°F / 10°C to 30°C
Atmospheric humidity: 80% rh @ to 30°C
Voltage fluctuations: -15% +10%
Installation category: II
Pollution degree: 2
Power supply voltage: 8.5-14.5V ac, 50/60 Hz, 4VA or 8.5-20V dc, 4W
Power Adapter: 12104881, 220V/50Hz
