B4400/4500/4550/4600 User’s Guide
14
Prepare the Image Drum
CAUTION! The green image drum surface is very delicate and
light sensitive. Do not touch it and do not expose it to sunlight
or room light for more than 5 minutes. If the drum unit needs
to be out of the printer for longer, please wrap it inside the
provided black plastic bag to keep it away from light.
1. Press the button on the right to open the top cover.
2. Open the manual tray and lift the blue tape.
3. Carefully lift the drum cartridge and remove the tape
with the protective film.
Fig1_36.jpg Fig1_35.jpg
To Next Page
