B4400/4500/4550/4600 User’s Guide
22
3. Insert the metal hook on each side of the Multi-purpose
feeder into the slots on each side of the printer.
Connect the connecting cord.
4. Insert a flat-blade screwdriver on the side of the
connector cover and move it downward to detach the
cover.
5. Move the cover piece up and down repeatedly until it
detaches from the printer.
6. Insert the connecting cord into the connector on the
printer, matching the arrows.
To Next Page
