Replacing consumable items> 67
7. Lower the fuser into the printer, locating the two lugs (3)
into their slots in the metal partition which separates the
fuser area from the image drums.
8. Push the two retaining levers (2) towards the rear of the
printer to lock the fuser in place.
9. Finally, close the top cover and press down firmly at both
sides so that the cover latches closed.
2
C
M
Y
K
