Oki C511 Maintenance Manual

44951501TH Rev.2
3-18
Oki Data CONFIDENTIAL
3. INSTALLATION
6. Insert an SD memory card into the slot.
Note! • SD memory cards are not usable when the safety switch against possible
erasure is in the active position, so be sure to move it to the inactive
position.
SCmemorycard
7. Attach the bracket and tighten the screw.
Bracket
Screw
10. Connect the power cord to the printer and turn the power ON.
9. Attach the connector cover to the printer.
Connector cover
8. Connect the printer cable to the printer.
Printer cable

Oki C511 Specifications

General

Print Technology	LED
Print Speed (B&W)	30 ppm
Print Speed (Color)	26 ppm
Resolution	1200 x 600 dpi
Connectivity	USB 2.0, Ethernet
Operating Systems Supported	Windows, macOS, Linux
