13 • Overview
Control Panel
1. Key Pad
Used to enter numbers, upper-case/lower-case letters and symbols in the Entry
Line. Refer to “Character Switching” on page 16 for further details.
2. Left Key
When in Switching mode: Returns the display to the Function Selection screen or
Scan Sub Function Selection screen from the Stand-by screen.
When Setting up: Increments the value of the tree structure.
3. Down Key
When setting up or in switching mode: Moves the cursor down.
4. Right Key
When in Switching mode:
• Used to confirm the Mode selected.
• Used to start Push scan (if push scan is selected, the executing Push Scan
screen is displayed.)
When Setting up:
• Decrements the value of the tree structure.
5. Up Key
When setting up or in Switching mode: Moves the cursor up.
