NETWORK SETTING Menu 1-7
Accessing the Network Setting Menu
Use the following series of keystrokes at the machine to access the Network
Setting menu options on your machine. This menu provides access to all of
the configurable network items.
Using the Network Setting Menu Options
If the machine is connected to a network, the following settings should be
specified. For details about each setting, contact your network administrator.
" To manually specify settings for the IP address, subnet mask and
gateway, set
IP ADDR. SETTING to SPECIFY.
" When entering the IP address, do not enter a class D (between
224.0.0.0 and 239.255.255.255) or class E (between 240.0.0.0 and
255.255.255.255) IP address.
In addition, “255” cannot be entered as the last three digits of the IP
address.
Press this
key . . .
(until) the message window reads . . .
UTILITY
MACHINE SETTING
ADMIN. MANAGEMENT
Use the keypad to input 6-digits administrator number.
ADMINISTRATOR NO.
NETWORK SETTING
To Next Page
