NETWORK SETTING Menu1-8
TCP/IP
IP ADDR. SETTING
Purpose Enables or disables TCP/IP.
If
ENABLE is selected, TCP/IP is enabled.
If DISABLE is selected, TCP/IP is disabled.
Options DISABLE/ENABLE
Default ENABLE
Purpose Sets the IP address of this machine on the network.
Sets the subnet mask of the network. The subnet mask
allows you to limit access to your machine (for example,
according to departmental divisions).
Sets the address of the router/gateway when a router/gate-
way is used on your network and you allow users outside
your network environment to print on your machine.
Options AUTO/SPECIFY
Default AUTO
(If IP ADDR. SETTING is set to SPECIFY)
IP ADDRESS: 0.0.0.0
SUBNET MASK: 255.255.255.0
GATEWAY: 0.0.0.0
Range (If IP ADDR. SETTING is set to SPECIFY)
0-255 for each xxx triplet
Use the keypad to input each number; use the and
keys to move between triplets.
Notes A single digit number, such as “1”, cannot be input as “001”.
Align the number on the left and input “1” as “1 _ _”. Use
the and keys to move between triplets.
The B
ACK key can also be used for deleting. To cancel IP
Address menu, hold down the BACK key for more than one
second, and then press the B
ACK key again after all set-
tings have been cleared.
