Oki ML186 - Page 51

51 • Operating Your Printer
(Set-Up) Print Registration 0.25 mm Right, 0.20 mm
Right, 0.15 mm Right, 0.10
mm Right, 0.05 mm Right, 0,
0.05 mm Left, 0.10 mm Left,
0.15 mm Left, 0.20 mm LEft,
0.25 mm Left
(Set-Up) 7 or 8 Bits Data
Word
ML emulation only.
8, 7
(Set-Up) Operator Panel
Function
FULL OPERATION, Semi
Operation*, Limited Operation
* When Limited Operation is
selected, after exiting the Menu,
only the SEL, LINE FEED and
FORM FEED buttons operate.
The PRINT QUALITY, TOF and
PITCH buttons are inactive.
(Set-Up) Reset Inhibit No, Yes
(Set-Up) Print Suppress
Effective
No, Yes
(Set-Up) Auto LF No, Yes
(Set-Up) Auto CR No, Yes
(Set-Up) SI Select Pitch (10
CPI)
15 CPI, 17.1 CPI
(Set-Up) SI Select Pitch (12
CPI)
12 CPI, 20 CPI
(Set-Up) TIme Out Print Valid, Invalid
(Set-Up) Auto Select No, Yes
(Set-Up) ESC SI Pitch 17.1 CPI, 20CPI
Group Item Setting
