Oki ML3390 User Manual

Help Guide 25
English
Reliability
Parameter Reliability
Mean Time Between Failures 10,000 hours at 25% duty
(MTBF) cycle and 35% page density
Mean Time to Repair 15 minutes
(MTTR)
Printhead Life 200 million characters
average in 10 cpi draft mode
at 25% duty and 35% page
density
Ribbon Life (on average, 2 million characters
10 cpi utility)
Paper Width Minimum: 3"
Maximum, ML 3390: 10"
Maximum, ML 3391: 16"
Paper Weight 45 to 90 g/m² (12 to 24 lb.)
Paper Thickness Rear Feed: 0.36mm (0.014") max.
Bottom Feed: 0.44mm (0.017") max.
Paper Specifications
Paper Type Feed Weight Width Range*
Cut sheets Top Only 58 - 90 g/m² ML3390: 182.9 - 215.9mm
(14-24 lb.) (7.2" - 8.5")
ML3391: 182.9 - 363.2mm
(7.2 to 14.3")
Single-part Rear, 45 - 90 g/m² ML3390: 76.2 - 254mm
continuous Bottom (12-24 lb.) (3-10")
forms ML3391: 76.2 - 406.4mm
(3-16")
Carbonless Rear, 34 - 41 g/m² ML3390: 76.2 - 254mm
continuous Bottom (9-11 lb.) (3-10")
forms ML3391: 76.2 - 406.4mm
(3-16")
Interleaf Rear, 38 - 45 g/m² ML3390: 76.2 - 254mm
continuous Bottom (10-12 lb.) (3-10")
forms Carbon 34g/m² ML3391: 76.2 - 406.4mm
(9 lb.) (3-16")
Labels Bottom ML3390: 76.2 - 254mm
Only (3-10")
ML3391: 76.2 - 406.4mm
(3-16")
3390hlp3.pm6 1/7/97, 04:3325

Oki ML3390 Specifications

General

Color	No
Built-in barcodes	Code 39, UPC-A, UPC-E
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	160
Media thickness	165 x 91 mm
Print technology	Dot matrix
Dimensions (WxDxH)	398 x 345 x 116 mm
Power requirements	220/230 VAC, 240V AC
Connectivity technology	Wired
Recommended media weight	45 - 90 g/m²
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	10000 h
