Oki ML3390 User Manual

26 ML3390/91
Paper Specifications (continued)
Paper Type Feed Weight Width Range*
Envelopes, Top Only 90 g/m² max. 165.1 - 241.3mm
single feed (24 lb.) (6.5" to 9.5")
Envelopes, Bottom 90 g/m² max. 165.1 - 241.3mm
continuous feed, Only (24 lb.) (6.5" to 9.5")
non-overlap
Card stock Bottom 178 g/m² max. N.A.
Only (48 lb.)
Transparencies Top Only — 215.9 - 279.4mm
(8.5" x 11")
Dimensions (W x D x H)
ML 3390: 15.7 x 13.6 x 4.6 inches
(398 x 345 x 116 mm)
ML 3391: 16.9 x 13.6 x 4.6 inches
(430 x 345 x 116 mm)
Weight ML 3390: TBD
ML 3391: TBD
Environmental Requirements
Parameter Range
Operating Temperature 5 to 40°C
Storage Temperature -10 to +50°C)
Operating Humidity 20 to 80% RH (max. wet
bulb temp. 30°C)
Storage Humidity 5 to 95% RH (max. wet
bulb temp. 40°C)
Electrical Requirements 230/240 volts ac (+10%, -14%),
50/60 Hz (±2%)
This product complies with the requirements of the Council
Directives 89/336/EEC and 73/23/EEC on the approximation of
the laws of the member states relating to electromagnetic
compatibility and low voltage.
Specifications subject to change without notice.
3390hlp3.pm6 1/27/97, 08:2526

Oki ML3390 Specifications

General

Color	No
Built-in barcodes	Code 39, UPC-A, UPC-E
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	160
Media thickness	165 x 91 mm
Print technology	Dot matrix
Dimensions (WxDxH)	398 x 345 x 116 mm
Power requirements	220/230 VAC, 240V AC
Connectivity technology	Wired
Recommended media weight	45 - 90 g/m²
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	10000 h
