MENU MODE > 35
Baud Rate, Default = 9600 bps
Appears only if optional Serial Interface is installed. Set this to match
your system’s transmission speed.
Bi-direction, Default = Enable
Change this setting if you wish to disable bi-directional transmission
(PnP) in Nibble mode.
Bottom Margin, Default = Valid
Change to Invalid if you want the printer to ignore the bottom margin
setting.
Busy Line, Default = SSD-
Appears only when the optional Serial Interface is installed. If Ready/
Busy protocol (factory default) is selected, you can choose which line
your system monitors for a busy signal:
l SSD -9V, select SSD-
l SSD +9V, select SSD+
l DTR -9V, select DTR
l RTS -9V, select RTS
Busy Time, Default = 200 ms
Appears only when the optional Serial Interface is installed. Sets the
length of the busy signal when the Ready/Busy protocol (factory
default) is engaged.
Centering Position, Default = DEFAULT
Used to limit printhead travel when printing narrow columns.
l Select Mode 1 for the narrow carriage printer.
l Select Mode 1 or Mode 2 for the wide carriage printer.
CAUTION!
Setting the Bottom Margin to Invalid can cause loss of data and
damage the printhead by allowing printing without paper.
