DESCRIPTION OF INSTRUCTIONS
265
Instruction code
CJNE @R1, #05H, TESTExample
10110111
70
Byte 1
Register 1
00110101
70
Before execution
Register 1
00110101
70
After execution
:
35H
00101011
70
35H
00101011
70
1
Carry flag
0
Carry flag
Program counter
15 8
0000000100011000
70
Program counter
15 8
0000000010110100
70
00000101
70
Byte 2
10011001
70
Byte 3
LOC
00B4
0118
011B
OBJ
2155
B70599
020500
SOURCE
TEST:AJMP TEST1
COMP:CJNE @R1, #05H, TEST
OUT:LJMP OUT1
