MSM80C154S/83C154S/85C154HVS
276
27. CPL C (Complement carry flag)
10110011
70
Instruction code
Operation
Number of bytes
Number of cycles
Flags
(PSW)
Description
Example CPL C
Instruction code
: Byte 1
(C)←(C):
C AC F0 RS1 RS0 OV F1 P
•
:
:
:
The carry flag is set to 1 if 0, set to 0 if 1.:
10110011
70
Byte 1
1
1
Before execution After execution
:
1
Carry flag
0
Carry flag
0
Carry flag
1
Carry flag
