MSM80C154S/83C154S/85C154HVS
298
44. JC code address (Jump if carry is set)
01000000
70
Instruction code
Relative offset
Operations
Number of bytes
Number of cycles
Flags
(PSW)
Description
: Byte 1
(PC)←(PC)+2
IF (C)=1
THEN
(PC)←(PC)+relative offset
:
C AC F0 RS1 RS0 OV F1 P
:
:
:
Control is shifted to a relative jump address if the carry flag is 1.
Control is shifted to the next address following this instruction if
the content is 0.
:
2
2
R7 R6 R5 R4 R3 R2 R1 R0
70
Byte 2
